1P NO 10A push button white - 09008

Pdf
Vimar - 09008 - 1P NO 10A push button white
Vimar - 09008 - 1P NO 10A push button white

09008
Wiring devices / Traditional wiring devices / NEVE UP / Devices

1P NO 10A push button white
1P NO 10 A 250 V~ push button, white

Product Status
3 - Active

You may also be interested in

09008.2
09008.2 - 1P NO 10A push button 2M white
09001
09001 - 1P 16AX 1-way switch white
09005
09005 - 1P 16AX 2-way switch white
09013
09013 - 1P 16AX reversing switch white
09050
09050 - 1P NO 10A name-plate push button white

Drawings

view encumbered art. 09008
PNG DXF
rear view art. 09008
PNG DXF
3D view art. 09008
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
47,00 mm
Device depth
35,90 mm

00. CE Marking - EU

07. INGCER - Chile

13. SNI-MGI - Indonesia

15. CCC - China

19. NOM - Mexico

29. QCERT - Colombia

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352296732
1 NR
4.1x2.8x5.3 [cm]
23.4 [g]
Barcode Qty 50 NR
8007352296749
50 NR
21.4x11.6x14.2 [cm]
1,270 [g]
Barcode Qty 500 NR
8007352296756
500 NR
57.5x22x29.5 [cm]
13,300 [g]
