6-button KNX control+actuator 3M - 01586

01586
Smart systems&products / KNX / Shared components / Devices

6-button KNX control+actuator 3M
6-button home automation device and NO 16 A 120-240 V~ 50/60 Hz relay output actuator, KNX standard, RGB LED location in darkness with brightness control, to be completed with interchangeable 1- or 2-module Eikon, Arké or Plana half-buttons - 2 modules

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Light Multilanguage instructions sheet (733 kb)
• Full Multilanguage instructions sheet (1104 kb)
• Manuale installatore (2893 kb)
• Installer manual (1926 kb)

Product Software

• DB_ComandoSupervisione_KNX_REL-01.17_20230117.zip
• DB_ComandoSupervisione_KNX_REL-01.18_20240618.zip

Video

• Universal home automation controls

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Multi operating device for bus system

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Radio frequent bidirectional
No

Width in number of modular spacings
3

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Matt

Colour
Other

RAL-number (similar)
7024

Transparent
No

With bus connection
Yes

00. CE Marking - EU

27. KNX

37. Marking - Morocco

46. UK PSTI compliance

92. RoHS UAE

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352593602

1 NR

5.7x5.3x7.7 [cm]

78.6 [g]

8007352633230

70 NR

39.5x30x17 [cm]

6,288.8 [g]
