V54420
System infrastructure / Enclosures and control units / Floor mount turrets / Flush mounting
Retractable turret 20M hollow cover
产品状态
3 - Active
Class group
Subfloor systems
Subfloor systems
Class
Device installation insert for subfloor installation
Device installation insert for subfloor installation
Cover model
Rectangular
Rectangular
Number of inlets
16
16
Number of device cups
1
1
Number of socket outlets with protective contact CEE 7/3 (type F)
0
0
Number of CEE socket outlets (IEC 60309) 16 A / 400 V / 5P (1, 2, 3, N, PE)
0
0
Number of CEE socket outlets (IEC 60309) 32 A / 400 V / 5P (1, 2, 3, N, PE)
0
0
Number of socket outlets British Standard BS1363
0
0
With cable outlet in cover
Yes
Yes
Lockable cover
Yes
Yes
Housing material
Plastic
Plastic
Surface protection housing
Untreated
Untreated
Material cover
Plastic
Plastic
Surface protection cover
Untreated
Untreated
Surface treatment cover
Untreated
Untreated
Cover load
1,5
1,5
Degree of protection (IP)
Other
Other
With opening carpeting
Yes
Yes
Protective frame carpeting
Yes
Yes
Colour
Other
Other
RAL-number
7021
7021
Suitable for indoor installation
Yes
Yes
Suitable for outdoor installation
No
No
Suitable for subfloor duct
Yes
Yes
Suitable for hollow floor
Yes
Yes
Suitable for double floor built-in
Yes
Yes
Suitable for concrete installation
No
No
Suitable for floors in computer rooms
Yes
Yes
Suitable for wet cleaning
Yes
Yes
Outer width
310,4 mm
310,4 mm
Outer length
305,4 mm
305,4 mm
Length built-in dimension
279,8 mm
279,8 mm
Width built-in dimension
284,8 mm
284,8 mm
Min. built-in depth
101,0 mm
101,0 mm
00. CE Marking - EU
最小订单数量: 1 NR
条形码
8007352735248
1 NR
37x37x13 [cm]
2,760 [g]
