Box for screed for turret 20M - V54920

Pdf

V54920
System infrastructure / Enclosures and control units / Floor mount turrets / Flush mounting

Box for screed for turret 20M

产品状态
3 - Active

Class group
Subfloor systems
Class
Device installation insert for subfloor installation
Cover model
Rectangular
Number of inlets
16
Number of device cups
1
Number of socket outlets with protective contact CEE 7/3 (type F)
0
Number of CEE socket outlets (IEC 60309) 16 A / 400 V / 5P (1, 2, 3, N, PE)
0
Number of CEE socket outlets (IEC 60309) 32 A / 400 V / 5P (1, 2, 3, N, PE)
0
Number of socket outlets British Standard BS1363
0
With cable outlet in cover
Yes
Lockable cover
Yes
Housing material
Stainless steel
Surface protection housing
Untreated
Material cover
Stainless steel
Surface protection cover
Untreated
Surface treatment cover
Untreated
Degree of protection (IP)
Other
With opening carpeting
No
Protective frame carpeting
Yes
Colour
Other
Suitable for indoor installation
Yes
Suitable for outdoor installation
No
Suitable for subfloor duct
Yes
Suitable for hollow floor
No
Suitable for double floor built-in
Yes
Suitable for concrete installation
Yes
Suitable for floors in computer rooms
Yes
Suitable for wet cleaning
Yes
Outer width
306,0 mm
Outer length
310,0 mm
Length built-in dimension
310,0 mm
Width built-in dimension
306,0 mm
Min. built-in depth
105,0 mm

00. CE Marking - EU

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352735309
1 NR
32.2x31.2x12.5 [cm]
3,300 [g]
