Flat cover 2M - V71632

Pdf

V71632
System infrastructure / Enclosures and control units / Connector block boxes / Flush mounting

Flat cover 2M
Concealed decorative cover to be fixed using the support, for round flush mounting boxes for masonry and hollow walls, white

Product Status
3 - Active

You may also be interested in

Drawings

Class group
Connection material (electrotechnical)
Class
Cover for box/housing for built-in mounting in the wall/ceiling
Diameter
0 mm
Length
90,00 mm
For box-/housing length
70,00 mm
Width
90,00 mm
For box-/housing width
68 mm
Depth
3,50 mm
Shape
Round
Type of fastening
Plug-in cover
Model
Construction protective cover
Material
Plastic
Halogen free
Yes
Colour
White
With screws
Yes
Sealable
No
Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352589933
1 NR
1x1x1 [cm]
23.8 [g]
Barcode Qty 50 NR
8007352596924
50 NR
37.5x30x13.5 [cm]
1,534 [g]
Question: Is the mounting frame included?
Answer: The product is supplied with the mounting frame included.

Didn't find the answer you were looking for?

Ask a question

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
