Flush mounting box ø 60mm light blue - V71001

Pdf
Vimar - V71001 - Flush mounting box ø 60mm light blue
Vimar - V71001 - Flush mounting box ø 60mm light blue

V71001
System infrastructure / Enclosures and control units / Connector block boxes / Flush mounting

Flush mounting box ø 60mm light blue
ø 60 mm flush mounting box, (Glow Wire 650 °C), for masonry walls, light blue

  • Plenty of space of internal wiring
  • Knockouts designed for the insertion of pipes with various cross-sections
  • Accessories available: anti-mortar covers and decorative covers

Product Status
3 - Active

You may also be interested in

V71001.AU
V71001.AU - Flush mounting box ø 60mm light black
V71632
V71632 - Flat cover 2M
V71011
V71011 - Antimortar cover for ø60mm box yellow

Drawings

view encumbered art. V71001
PNG DXF
rear view art. V71001
PNG DXF
3D view art. V71001
PNG DXF
Class group
Connection material (electrotechnical)
Class
Box/housing for built-in mounting in the wall/ceiling
Mounting method
Flush-mounted
Shape
Round
Construction type
Device connection box (round/square)
Model
Other
Provided with revolving ring
No
Couplable
Yes
Equipped with
None
Diameter
60 mm
Length
60,00 mm
Width
60,00 mm
Depth
0,00 - 50,00 mm
Inner depth
50,00 mm
For number of electric fittings
2
Mounting switching equipment
Spread
With screws
No
Housing feed-through by break-out opening
Yes
Housing feed-through by seal membrane
No
Housing feed-through by nozzle
No
Housing feed-through by step membrane
No
For tube diameter
20/25 mm
Pipe locking
No
Pipe locking optional
No
Inlet from the rear
Yes
Number of inlets
5
Number of included spouts
0
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Blue
Degree of protection (IP)
IP00
Cover model
None
Transparent cover
No
Cover attachment
Screwed
Sealable
No
Circuit integrity
None
With screening
No
Air tight
No
Max. conductor cross section
0
Number of poles of the clamp
0
Clamp position fixed
No
Luminaire hook mounting
No
Nozzle
None
Special application
None

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352079281
1 NR
6x6x5 [cm]
15 [g]
Barcode Qty 10 NR
8007352083059
10 NR
25x14x7 [cm]
151.8 [g]
Barcode Qty 200 NR
8007352111080
200 NR
59x38.5x30 [cm]
3,860 [g]
