1P 10AX 2-way switch+P30 outlet white - 06697.B

Pdf
Vimar - 06697.B - 1P 10AX 2-way switch+P30 outlet white
Vimar - 06697.B - 1P 10AX 2-way switch+P30 outlet white

06697.B
Wiring devices / Traditional wiring devices / MASCOT / Devices

1P 10AX 2-way switch+P30 outlet white
1P 10 AX 250 V~ 2-way switch + 2P+E 16 A 250 V~ SICURY socket outlet, Italian standard P30 (lateral and central earth contacts), white

Product Status
2 - Will be discontinued

You may also be interested in

V71001
V71001 - Flush mounting box ø 60mm light blue
V71001.AU
V71001.AU - Flush mounting box ø 60mm light black
V71701
V71701 - Round flush-mount box f/hollow wall blue
Class group
Domestic switching devices
Class
Combination switch/wall socket outlet
Type of switch
Two-way switch
Type of socket outlet
Other
Number of socket outlets
1
Method of operation
Rocker/button
Mounting direction
Horizontal and vertical
Type of fastening
Mounting with claw
With lighting
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9003
Transparent
No
Suitable for degree of protection (IP)
IP20
Nominal voltage
250 V
Nominal current socket outlet
16 A
Rated current
16 A
Over voltage protection
No
Fault current protection
No
Device width
80,00 mm
Device height
80,00 mm
Device depth
36 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352095502
1 NR
8x8x3.6 [cm]
89.87 [g]
Barcode Qty 20 NR
8007352095656
20 NR
35.5x24.8x8.7 [cm]
2,026.73 [g]
