1P 10AX 2-way switch+P17/11outlet ivory - 06690

Pdf
Vimar - 06690 - 1P 10AX 2-way switch+P17/11outlet ivory
Vimar - 06690 - 1P 10AX 2-way switch+P17/11outlet ivory

06690
Wiring devices / Traditional wiring devices / MASCOT / Devices

1P 10AX 2-way switch+P17/11outlet ivory
1P 10 AX 250 V~ 2-way switch + 2P+E 16 A 250 V~ SICURY Bpresa socket outlet, Italian standard P17/11, ivory

Product Status
2 - Will be discontinued

You may also be interested in

V71001
V71001 - Flush mounting box ø 60mm light blue
V71001.AU
V71001.AU - Flush mounting box ø 60mm light black
V71701
V71701 - Round flush-mount box f/hollow wall blue
Class group
Domestic switching devices
Class
Combination switch/wall socket outlet
Type of switch
Two-way switch
Type of socket outlet
Other
Number of socket outlets
1
Method of operation
Rocker/button
Mounting direction
Horizontal and vertical
Type of fastening
Mounting with claw
With lighting
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9001
Transparent
No
Suitable for degree of protection (IP)
IP20
Nominal voltage
250 V
Nominal current socket outlet
16 A
Rated current
16 A
Over voltage protection
No
Fault current protection
No
Device width
80,00 mm
Device height
80,00 mm
Device depth
36 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352095472
1 NR
8x8x3.6 [cm]
74.31 [g]
Barcode Qty 20 NR
8007352098497
20 NR
31x24.8x8.7 [cm]
1,708.87 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
