Quid - Step relay module 10A+reset - 03992

Pdf

03992
Wiring devices / Traditional wiring devices / Shared components / Non-modular components

Quid - Step relay module 10A+reset
Quid magnetic relay module with sequential ON/OFF pulses, 1 input for NO push button, 1 input for reset push button, 1 NO 10 A 220-240 V~ 50/60 Hz relay output, light signal for the load status on each individual push button, flush mounting (retrofit, shunting or under blank module)

Product Status
3 - Active

You may also be interested in

Class group
Relays
Class
Switching relay
Complete with socket
No
With detachable clamps
No
With forced-guided contacts
No
Nominal current
10 A
Height
54,50 mm

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352623224
1 NR
6x5.4x5.3 [cm]
54 [g]
Barcode Qty 10 NR
8007352623231
10 NR
28.1x13.1x6 [cm]
614 [g]
Barcode Qty 120 NR
8007352623248
120 NR
38.5x29x30 [cm]
7,862 [g]
Barcode Qty 170 NR
8007352755949
170 NR
39x29.5x22 [cm]
9,180 [g]
