Axial 1P 10AX reversing switch white - 30012A.B

Pdf
Vimar - 30012A.B - Axial 1P 10AX reversing switch white
Vimar - 30012A.B - Axial 1P 10AX reversing switch white

30012A.B
Wiring devices / Traditional wiring devices / LINEA / Devices

Axial 1P 10AX reversing switch white
1P 10 AX 250 V~ lightable axial reversing switch, replaceable button, white. Max 100 W for lamps with built-in power supply unit (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

30000A.B
30000A.B - Axial 1P 10AX 1-way switch white
30004A.B
30004A.B - Axial 1P 10AX 2-way switch white
30008A.B
30008A.B - Axial 1P NO 10A button white
00943.W
00943.W - Linea 110-250V white LED unit

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Intermediate switch
Method of operation
Other
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Label space/information surface
No
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Impact strength
Other
Nominal voltage
250 V
Rated current
10,00 A
Switching current for fluorescent lamps
10
Feedback-signal contact
No
Connection type
Screwed terminal
Heating switch
No
Washing machine switch
No
Device width
22,30 mm
Device height
52,80 mm
Device depth
41,20 mm
Built-in depth
35,50 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

01. IMQ - Italy

13. SNI - Indonesia

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352682849
1 NR
4.6x2.7x5.6 [cm]
38.34 [g]
Barcode Qty 50 NR
8007352682856
50 NR
23.7x14.8x12.8 [cm]
1,917 [g]
Barcode Qty 300 NR
8007352682863
300 NR
45.5x27x27 [cm]
11,502 [g]
