Axial 1P 10AX 2-way switch white - 30004A.B

Pdf
Vimar - 30004A.B - Axial 1P 10AX 2-way switch white
Vimar - 30004A.B - Axial 1P 10AX 2-way switch white

30004A.B
Wiring devices / Traditional wiring devices / LINEA / Devices

Axial 1P 10AX 2-way switch white
1P 10 AX 250 V~ lightable axial 2-way switch, replaceable button, white. Max 100 W for lamps with built-in power supply unit (IEC 60669-1:2017)

产品状态
3 - Active

您可能也感兴趣

30000A.B
30000A.B - Axial 1P 10AX 1-way switch white
30008A.B
30008A.B - Axial 1P NO 10A button white
30012A.B
30012A.B - Axial 1P 10AX reversing switch white
00943.W
00943.W - Linea 110-250V white LED unit

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Other
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Label space/information surface
No
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Impact strength
Other
Nominal voltage
250 V
Rated current
10,00 A
Switching current for fluorescent lamps
10
Feedback-signal contact
No
Connection type
Screwed terminal
Heating switch
No
Washing machine switch
No
Device width
22,30 mm
Device height
52,80 mm
Device depth
37,50 mm
Built-in depth
31,80 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

01. IMQ - Italy

13. SNI-MGI - Indonesia

37. Marking - Morocco

50. Product Environm. Profile

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352675155
1 NR
4.6x2.7x5.6 [cm]
32.58 [g]
Barcode Qty 50 NR
8007352675162
50 NR
23.7x14.8x12.8 [cm]
1,770 [g]
Barcode Qty 300 NR
8007352675179
300 NR
45.5x27x27 [cm]
11,050 [g]
Barcode Qty 5,400 NR
8007352749856
5,400 NR
120x80x105 [cm]
198,882 [g]
