Vimar - 22642.01 - Plate 2M metal matt white

22642.01
Wiring devices / Traditional wiring devices / EIKON / Cover plates

Plate 2M metal matt white
2-module cover plate, metal Total Look, matt white

产品状态
3 - Active

您可能也感兴趣

21602 - Frame 2M +claws 71mm

21603 - Frame 2M without screws 71mm

图纸

PNG DXF

Class group
Domestic switching devices

Class
Cover frame for domestic switching devices

Number of units
2

Mounting direction
Horizontal and vertical

Number of units horizontal
2

Number of units vertical
1

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With mounting grid
Yes

Suitable for subfloor installation duct box
Yes

Suitable for wall duct
Yes

Suitable for built-in installation
Yes

Label space/information surface
Yes

Material
Metal

Material quality
Other

Surface protection
Lacquered

Surface finishing
Matt

Colour
White

RAL-number (similar)
9003

Transparent
No

With hinged lid
No

Degree of protection (IP)
IP00

Type of fastening
Clamp mounting

Width
90,00 mm

Height
90,00 mm

Depth
10,15 mm

Built-in width
90,00 mm

Built-in height
90,00 mm

Diameter bore hole (opening)
0 mm

00. CE Marking - EU

01. IMQ - Italy

08. ASTA - UK

29. QCERT - Colombia

50. Product Environm. Profile

最小订单数量: 1 NR

条形码

8007352608504

1 NR

9.6x9.6x1.7 [cm]

141.4 [g]

8007352608511

5 NR

10.2x10x10.4 [cm]

746.4 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
