Frame 2M +claws 71mm

Pdf

21602
Wiring devices / Traditional wiring devices / EIKON / Mounting frames

Frame 2M +claws 71mm
2-module mounting frame, with claws, for ø 60 mm mounting boxes, 71 mm distance between centres

The honeycomb structure gives structural strength
The slots in the corners enable fixing to the panel
The hooking teeth encourage fixing in series for the installation of multiple modules

产品状态
3 - Active

您可能也感兴趣

21602.C - Cover 2M Eikon mount-frame

图纸

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with claw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
No

Suitable for mounting in round junction box 60 mm
Yes

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

50. Product Environm. Profile

96. Electrotechnical expert

最小订单数量: 50 NR

条形码

8007352421349

1 NR

7.4x7.4x2.4 [cm]

27.6 [g]

8007352421356

50 NR

28.4x24.4x11.9 [cm]

1,465.2 [g]

8007352651005

300 NR

59.5x38.5x26.5 [cm]

9,420 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
