IoT dial thermostat 2M grey - 02973

Pdf

02973
Wiring devices / View Wireless wiring devices / Shared components / Devices

IoT dial thermostat 2M grey
Dial thermostat with relay output 5(2) A 240 V~, IoT technology on Bluetooth technology 5.0 standard for the creation of View Wireless mesh system, 1 input for external temperature sensor, 100-240 V~ 50/60 Hz power supply, heating and air conditioning in ON/OFF and PID mode, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, white LED backlighting with brightness control, 100-240 V 50/60 Hz power supply, grey - 2 modules. To be completed with Eikon, Arké and Plana cover plates, for Idea with dedicated mounting frame 16723

  • Compatible with Alexa, Google Home and IFTTT, using the dedicated gateway
  • Configuration via “VIEW Wireless” App for Bluetooth technology system
  • Hotkeys are designed for quick interaction

产品状态
3 - Active

Class group
Stats, switches and controllers
Class
Room thermostat
Model
On/Off
Type of power supply
230 V AC
Connection
3-/4-wire
With receiver
No
External sensor
Yes
Thermal feedback
Parallel
Control characteristic
PID
Suitable for heating
Yes
Number of heater outputs
1
Number of cooler outputs
1
Adjustable differential
Yes
Temperature readable
Yes
With sound indicator
No
Sensor/feeler type
Resistance sensor
Mounting method
Flush-mounted
Number of modules (module system)
2
With display
Yes
Operation
Turn
With tap water circuit
No
Max. contact voltage
230 V
Max. contact load
5 A
Degree of protection (IP)
IP30
Explosion-proof
No
Colour
Grey
RAL-number
7024
Height
49,00 mm
Width
44,80 mm
Depth
41,50 mm
Diameter
0 mm
Class of the temperature control
IV

29. QCERT - Colombia

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

92. RoHS UAE

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352657526
1 NR
5.7x5.3x7.7 [cm]
81.6 [g]
Barcode Qty 60 NR
8007352746466
60 NR
37.5x30x13.5 [cm]
5,209.2 [g]
Barcode Qty 70 NR
8007352657533
70 NR
39.5x30x17 [cm]
6,078 [g]
问题: What is the difference between the IoT connected dial thermostat and the home automation system dial thermostat?
回答: 02973: Thermostat for IoT connected Wireless system, in other words our system which, via the Bluetooth Mesh protocol, enables various devices in the range to communicate with one another via Wireless and to be managed via the VIEW App through the IoT connected gateway. 02971: Thermostat for By-me Plus home automation system, in other words Vimar’s home automation system via wired BUS for the creation of larger-spanning Home Automation systems of greater technical complexity.
问题: Does the thermostat have the same functions as a timer-thermostat (daily or weekly temperature control, holidays etc.)?
回答: Product art. 02973, if linked to a connected gateway (e.g. art. 14597 for the Plana series) and managed via the VIEW App, makes it possible to achieve the weekly timer-thermostat programming function, for which up to 3 customised temperature levels can be defined for every day of the week.
问题: In order to control the temperature in the various rooms, does the dial thermostat connect to the radiator thermostatic valves?
回答: The connected thermostat is not designed to interface directly with a smart thermostatic valve, but to manage via its on-board relay a traditional solenoid valve connected to it by a wire.
