Supply unit from 12-24V to 29V - 01970

Pdf
Vimar - 01970 - Supply unit from 12-24V to 29V
Vimar - 01970 - Supply unit from 12-24V to 29V

01970
Smart systems&products / By-me Plus / Shared components / DIN devices

Supply unit from 12-24V to 29V
Power supply with 29 V d.c. 800 mA output, supply voltage 12-24 V~ 50-60 Hz or 12-24 V d.c. (SELV), with decoupling coil, for EN 50022 rail installation, occupies 9 17,5 mm modules. For nautical scope

产品状态
3 - Active

Class group
Installation bus systems
Class
Power supply for bus system
Bus system KNX
Yes
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Mounting method
DRA (DIN-rail adapter)
Width in number of modular spacings
9
With LED indication
No
Bus voltage stockable
No
Number of lines to feed
2
Max. output current
800,00 mA

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352347342
1 NR
27.6x16.9x11.1 [cm]
655.8 [g]
