01410
Smart systems&products / View smart system / Shared components / DIN devices
By-me home automation Light Gateway
IoT gateway for integration, configuration and local or remote maintenance of the By-me Plus home automation system, via IP/LAN network, Cloud and app for smartphone, tablet, PC or IP supervision touch screens, light version for max 32 By-me Plus devices, for DIN (60715 TH35) rail installation, occupies 4 17.5 mm modules
产品状态
3 - Active
单, 说明书, 文档
- Multilanguage instructions sheet (1105 kb)
- Manuale piattaforma View IoT Smart Syst. (9599 kb)
- Manuel installateur app View Pro (6937 kb)
- Manual del instalador View Pro (6921 kb)
- Installer manual View IoT Smart Systems (7021 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (7114 kb)
- Installationsanleitung View Pro (6907 kb)
- Manuale installatore Sistema By-me Plus (30061 kb)
- Manuel installateur By-me Plus (22198 kb)
- Manual del instalador By-me Plus (22244 kb)
- Installer manual By-me Plus System (22392 kb)
- Συνδεδεμένο σύστημα smart automation (22738 kb)
- Installationsanleitung By-me Plus (22257 kb)
产品配套软件
图纸
Class group
Installation bus systems
Installation bus systems
Class
System interface/media gateway for bus system
System interface/media gateway for bus system
Bus system KNX
No
No
Bus system KNX-RF (Radio Frequent)
No
No
Bus system radio frequent
No
No
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
Other
Other
Radio frequent bidirectional
No
No
Model
Ethernet interface
Ethernet interface
Mounting method
DRA (DIN-rail adapter)
DRA (DIN-rail adapter)
Width in number of modular spacings
4
4
Demounting protection
No
No
With LED indication
Yes
Yes
Updateable
Yes
Yes
Protocol
TCP/IP
TCP/IP
Provider dependent
No
No
Visualization
No
No
Web-Server
Yes
Yes
Radio interface
No
No
IR interface
No
No
Degree of protection (IP)
IP40
IP40
00. CE Marking - EU
37. Marking - Morocco
37. Marking - Morocco
92. RoHS UAE
最小订单数量: 1 NR
条形码
8007352586123
1 NR
11.7x10.8x7.1 [cm]
174 [g]
8007352590588
60 NR
59x38.5x30 [cm]
11,190 [g]
| 问题： | Can the gateway act as a control unit and also provide you the possibility of accessing controls via Internet/App directly? |
|---|---|
| 回答： | Gateway art. 01411 performs the control unit functions (configurator) but also those of the supervisor (once those of the Web Server 01945) as well as those of a logic unit. Within 32 home automation system devices installed and fitted with a BUS terminal, the light version of the automations gateway art. 01410 is enough |
| 问题： | Can a SIM module be inserted? |
| 回答： | There is no possibility of applying a “SIM module” directly to the device to enable its remote connection; nevertheless, by inserting a 4G Router in the network connected to the gateway via an Ethernet cable, the desired result can still be achieved. |
