01422
Smart systems&products / View smart system / Surface mounting components / Non-modular components
IP 7in touch screen PoE black
Touch screen with 7” IP capacitive colour display, used as a home automation system supervisor, IP/Due Fili Plus internal video entryphone, IP video camera and CCTV system manager, power supply PoE or 12-30 Vdc, surface mounting with bracket on round, 3-module (horizontal or vertical), 8-module 4+4) or Britisch standrad square mounting box, black
产品状态
3 - Active
单, 说明书, 文档
- Multilanguage instructions sheet (1415 kb)
- Manuale piattaforma View IoT Smart Syst. (9599 kb)
- Manuel installateur app View Pro (6937 kb)
- Manual del instalador View Pro (6921 kb)
- Installer manual View IoT Smart Systems (7021 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (7114 kb)
- Installationsanleitung View Pro (6907 kb)
- Manuale utente touch screen (6113 kb)
- User Manual Touch screen (5444 kb)
图纸
Class group
Installation bus systems
Installation bus systems
Class
Signalling and operation panel for bus system
Signalling and operation panel for bus system
Bus system KNX
No
No
Bus system KNX-RF (Radio Frequent)
No
No
Bus system radio frequent
No
No
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
Other
Other
Radio frequent bidirectional
No
No
Assembly arrangement
Other
Other
Model
Signalling and operating panel
Signalling and operating panel
Mounting method
Flush-mounted
Flush-mounted
Text field
No
No
Display
Colour
Colour
Touch function
Yes
Yes
Additional interfaces
Ethernet
Ethernet
With bus connection
No
No
Material
Glass
Glass
Material quality
Other
Other
Colour
Black
Black
RAL-number (similar)
9004
9004
Degree of protection (IP)
IP20
IP20
最小订单数量: 1 NR
条形码
8007352586062
1 NR
25.5x22.4x5.3 [cm]
991.4 [g]
8007352612624
7 NR
39x29.5x22 [cm]
7,332 [g]
