Lower 1M path light button Canvas - 31000S.C

Pdf
Vimar - 31000S.C - Lower 1M path light button Canvas
Vimar - 31000S.C - Lower 1M path light button Canvas

31000S.C
Wiring devices / Traditional wiring devices / LINEA / Buttons

Lower 1M path light button Canvas
Aligned 1-module interchangeable button, with vertical light beam, canvas

Product Status
3 - Active

You may also be interested in

30000
30000 - 1P 10AX 1-way switch mechanism
30004
30004 - 1P 10AX 2-way switch mechanism
30008
30008 - 1P NO 10A button mechanism
30012
30012 - 1P 10AX reversing switch mechanism

Drawings

view encumbered art. 31000S.C
PNG DXF
rear view art. 31000S.C
PNG DXF
3D view art. 31000S.C
PNG DXF
Class group
Domestic switching devices
Class
Control element/cover plate for domestic switching devices
Model
Other
Imprint/indication
Symbol ˝light˝
Scannable symbol/barrier free
No
Utilization
Switch/push button
Suitable for touch sensor connector for bus system
No
Type of fastening
Engage (snap)
Monitoring window/light outlet
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Anti-bacterial treatment
No
Colour
Beige
RAL-number (similar)
7032
With label area
No
With exchangeable lens/symbol
No
Suitable for degree of protection (IP)
IP40
Width
2.230,00 mm
Height
5.280,00 mm
Depth
910,00 mm

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352693463
1 NR
10x5x1.5 [cm]
3.86 [g]
Barcode Qty 20 NR
8007352693470
20 NR
19.8x11.5x6.8 [cm]
142.64 [g]
Barcode Qty 160 NR
8007352693487
160 NR
36x22.5x19.5 [cm]
1,450.64 [g]
