IoT dial thermostat 2M black - 30810.G

Pdf
Vimar - 30810.G - IoT dial thermostat 2M black
Vimar - 30810.G - IoT dial thermostat 2M black

30810.G
Wiring devices / View Wireless wiring devices / LINEA / Devices

IoT dial thermostat 2M black
Dial thermostat with relay output 5(2) A 240 V~, IoT technology on Bluetooth technology 5.0 standard for the creation of VIEW Wireless mesh system, 1 input for external temperature sensor, 100-240 V~ 50/60 Hz power supply, heating and air conditioning in ON/OFF and PID mode, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, white LED backlighting with brightness control, black - 2 modules.

  • It is compatible with voice assistants Alexa and Google Home through Skill and Action VIEW Product
  • Maximum simplicity thanks to the large knob
  • Configuration via “VIEW Wireless” App for Bluetooth technology system
  • Hotkeys are designed for quick interaction

Product Status
3 - Active

You may also be interested in

30807.G
30807.G - IoT connected Gateway 2M black
Class group
Stats, switches and controllers
Class
Room thermostat
Model
Other
Type of power supply
230 V AC
Connection
3-/4-wire
With receiver
No
Measuring range
0 - 40 °C
External sensor
Yes
Thermal feedback
Parallel
Control characteristic
PID
Suitable for heating
Yes
Number of heater outputs
1
Suitable for cooling
Yes
Number of cooler outputs
1
Differential value
0,10 - 1,00 k
Adjustable differential
Yes
Temperature readable
Yes
With sound indicator
No
Sensor/feeler type
Resistance sensor
Mounting method
Flush-mounted
Number of modules (module system)
2
With display
Yes
Operation
Turn
With tap water circuit
No
Contact type
Normally open contact (NO)
Max. contact voltage
230 V
Max. contact load
5 A
Degree of protection (IP)
IP20
Degree of protection (NEMA)
Other
Explosion-proof
No
Colour
Black
RAL-number
7021
Height
52,80 mm
Width
44,80 mm
Depth
41,70 mm
Diameter
0 mm
Class of the temperature control
IV
Compatible with Apple HomeKit
Yes
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes
IFTTT support available
Yes

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352689367
1 NR
6x5.4x5.2 [cm]
71 [g]
Barcode Qty 10 NR
8007352689374
10 NR
28.1x13.1x6 [cm]
799.8 [g]
Barcode Qty 120 NR
8007352689381
120 NR
38.5x29x30 [cm]
10,040 [g]
