16A IoT connected actuator black - 30803.G

Pdf
Vimar - 30803.G - 16A IoT connected actuator black
Vimar - 30803.G - 16A IoT connected actuator black

30803.G
Wiring devices / View Wireless wiring devices / LINEA / Devices

16A IoT connected actuator black
View Wireless connected electronic control device with NO 16(3,5)A 100-240 V~ 50/60 Hz relay output, local control with push button or remote control, double technology with Bluetooth® wireless technology 5.0 standard for the realization of View Wireless mesh system and Zigbee 3.0 standard, function for measuringthe instant power and load cut-off threshold, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, black

  • Compatible with SmartThings hub

Product Status
3 - Active

You may also be interested in

30807.G
30807.G - IoT connected Gateway 2M black
Class group
Installation bus systems
Class
Switch actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
Yes
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Radio frequent bidirectional
Yes
Mounting method
Flush-mounted
Width in number of modular spacings
1
Local operation/hand operation
Yes
With LED indication
Yes
Number of digital inputs
0
Suitable for C-load
Yes
Max. number of switching contacts
1
Max. switching current
16 A
Rated current
16 A
Rated operating voltage
100,00 - 240,00 V
Different phases connectable
No
With bus connection
Yes
Bus module detachable
No
Modular expandability
No
Degree of protection (IP)
IP40

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352690158
1 NR
6x4.5x5.4 [cm]
56.96 [g]
Barcode Qty 72 NR
8007352744905
72 NR
37.5x30x13.5 [cm]
4,504.75 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
