Plate 7M techno black - 30657.02

Pdf
Vimar - 30657.02 - Plate 7M techno black
Vimar - 30657.02 - Plate 7M techno black

30657.02
Wiring devices / Traditional wiring devices / LINEA / Cover plates

Plate 7M techno black
7-module cover plate, technopolymer, black

Product Status
3 - Active

You may also be interested in

30617
30617 - Frame 7M + screws

Drawings

view encumbered art. 30657.02
PNG DXF
rear view art. 30657.02
PNG DXF
3D view art. 30657.02
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
7
Mounting direction
Horizontal and vertical
Number of units horizontal
7
Number of units vertical
1
Number of modules horizontal (module system)
7
Number of modules vertical (module system)
1
With mounting grid
Yes
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Matt
Colour
Black
RAL-number (similar)
7021
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Engage (snap)
Width
208,50 mm
Height
88,00 mm
Depth
10,40 mm
Built-in width
208,50 mm
Built-in height
2,50 mm
Diameter bore hole (opening)
0 mm

00. CE Marking - EU

01. IMQ - Italy

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352696174
1 NR
9.7x28.4x0.9 [cm]
35.4 [g]
Barcode Qty 5 NR
8007352696198
5 NR
10.5x6x29 [cm]
257.2 [g]
Barcode Qty 40 NR
8007352696204
40 NR
30.5x26x23 [cm]
2,364 [g]
