19179
Wiring devices / View Wireless wiring devices / ARKÉ / Devices
IoT connected radar sensor 1M grey
Product Status
3 - Active
Sheets, Manuals, Documentation
- Light Multilanguage instructions sheet (1346 kb)
- Foglio istruzioni Full (1138 kb)
- Feuille d’instructions Full (1139 kb)
- Hoja de instrucciones Full (1138 kb)
- Full Instructions sheet (1135 kb)
- Φυλλάδιο οδηγιών Full (1219 kb)
- Anweisungsblatt Full (1139 kb)
- ورقة الإرشادات Full (1219 kb)
- Manuale app View Wireless (16695 kb)
- Manuel appli View Wireless (36896 kb)
- Manual app View Wireless (36835 kb)
- Manual View Wireless app (36774 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (37151 kb)
- Installationsanleitung View Wireless (36685 kb)
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
Movement sensor/presence detector complete
Movement sensor/presence detector complete
Model
Movement sensor
Movement sensor
Sensor type
High frequency
High frequency
With DALI interface
No
No
Constant light control
No
No
HVAC-control
No
No
Forced switch on
Yes
Yes
Forced switch off
No
No
Animal zone
Yes
Yes
Creep-under protection
No
No
Networkable
Yes
Yes
Scan angle
100
100
Staircase light controller
No
No
Bridging switch
No
No
Max. reach frontally
7 m
7 m
Suitable for wireless transmission
Yes
Yes
Remote operation
Yes
Yes
With remote control
No
No
Response value sensitivity adjustable
Yes
Yes
With signal unit
Yes
Yes
Teach-function for response value luminosity
No
No
Dim function with dimmer basic element
No
No
Mounting method
Flush-mounted
Flush-mounted
Suitable for ceiling mounting
No
No
Connection type
Screwed terminal
Screwed terminal
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Anti-bacterial treatment
No
No
Colour
Grey
Grey
RAL-number (similar)
7015
7015
Transparent
No
No
Degree of protection (IP)
IP40
IP40
Voltage type
AC
AC
Frequency
50 - 60 HZ
50 - 60 HZ
Min. switch-on time
70 s
70 s
Switch-off delay
1.080 s
1.080 s
Detection angle horizontal
0 - 100
0 - 100
Max. switching power
960,00 W
960,00 W
Temperature
10 - 40 °C
10 - 40 °C
Number of switching zones
1
1
Min. starting current
0 A
0 A
Substation input
No
No
With alarm function
Yes
Yes
Width
2.230,00 mm
2.230,00 mm
Height
49,00 mm
49,00 mm
Depth
4.970,00 mm
4.970,00 mm
Diameter
0,00 mm
0,00 mm
Built-in depth
3.950,00 mm
3.950,00 mm
Built-in diameter
0,00 mm
0,00 mm
Compatible with Apple HomeKit
Yes
Yes
Compatible with Google Assistant
Yes
Yes
Compatible with Amazon Alexa
Yes
Yes
00. CE Marking - EU
00. CE Marking - EU
37. Marking - Morocco
40. Bluetooth technology
92. RoHS UAE
Minimum order quantity: 1 NR
Barcode
8007352709331
1 NR
6x5.4x5.2 [cm]
46.4 [g]
8007352709348
10 NR
28.1x13.1x6 [cm]
539.8 [g]
