Plate 2centrM techn.black - 09672.04

Pdf
Vimar - 09672.04 - Plate 2centrM techn.black
Vimar - 09672.04 - Plate 2centrM techn.black

09672.04
Wiring devices / Traditional wiring devices / NEVE UP / Cover plates

Plate 2centrM techn.black
2-module central cover plate for 3-module mounting boxes, technopolymer, black

Product Status
3 - Active

You may also be interested in

09606
09606 - Horizontal frame 2centralM+screws
09607
09607 - Vertical frame 2centralM+screws

Drawings

view encumbered art. 09672.04
PNG DXF
rear view art. 09672.04
PNG DXF
3D view art. 09672.04
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
2
Mounting direction
Horizontal and vertical
Number of units horizontal
2
Number of units vertical
1
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Colour
Black
RAL-number (similar)
9005
Transparent
No
With hinged lid
No
Type of fastening
Clamp mounting
Width
120,00 mm
Height
86,00 mm
Depth
8,50 mm
Built-in width
120,00 mm

00. CE Marking - EU

29. QCERT - Colombia

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352662797
1 NR
13x9.9x0.9 [cm]
18.37 [g]
Barcode Qty 10 NR
8007352662803
10 NR
17.1x9.8x9.9 [cm]
236.94 [g]
Barcode Qty 360 NR
8007352670280
360 NR
59x34.5x32.5 [cm]
9,279.84 [g]
