Vertical frame 2centralM+screws - 09607

09607
Wiring devices / Traditional wiring devices / NEVE UP / Mounting frames

Vertical frame 2centralM+screws
2-central-module frame for vertical mounting, with screws, for 3-module mounting boxes or boxes with 60 mm fixing centres

Product Status
3 - Active

You may also be interested in

07935.1 - Screw for frame fixing - 24mm

07937 - Screw for frame fixing - 35mm

07939 - Screw for frame fixing - 50 mm

09613 - Frame 3M +screws

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Holder for modular domestic switching devices

Model
Flush-mounted

Mounting method
Mounting with screw

Mounting method of the module inserts
Front side

Mounting direction
Horizontal and vertical

Number of modules horizontal (module system)
2

Number of modules vertical (module system)
1

With built-in installation box
No

With screws
Yes

Suitable for mounting in round junction box 60 mm
No

Flush-mounted installation
Yes

Suitable for subfloor installation duct box
No

Suitable for wall duct
No

Suitable for mounting on DIN-rail 35 mm
No

Material
Plastic

Material quality
Thermoplastic

00. CE Marking - EU

29. QCERT - Colombia

96. Electrotechnical expert

Minimum order quantity: 10 NR

---

Barcode

8007352391574

1 NR

11.8x6.5x1.7 [cm]

23.31 [g]

8007352391581

10 NR

11.8x6.5x17 [cm]

233.1 [g]

8007352391598

200 NR

35x33.5x24.5 [cm]

4,662 [g]
