Frame 2M for RF device white - 09507

Pdf
Vimar - 09507 - Frame 2M for RF device white
Vimar - 09507 - Frame 2M for RF device white

09507
Smart systems&products / Smart switch&sound / NEVE UP / Mounting frames

Frame 2M for RF device white

Product Status
3 - Active

Drawings

view encumbered art. 09507
PNG DXF
rear view art. 09507
PNG DXF
3D view art. 09507
PNG DXF
Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
With nail
No
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
2
With built-in installation box
No
With screws
No
Suitable for mounting in round junction box 60 mm
Yes
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated

00. CE Marking - EU

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352732667
1 NR
8.4x8.4x0.8 [cm]
23 [g]
Barcode Qty 10 NR
8007352732674
10 NR
18.8x13.8x7 [cm]
245 [g]
