2P+E 16A Israeli SICURY outlet white - 09240

Pdf
Vimar - 09240 - 2P+E 16A Israeli SICURY outlet white
Vimar - 09240 - 2P+E 16A Israeli SICURY outlet white

09240
Wiring devices / Traditional wiring devices / NEVE UP / Devices

2P+E 16A Israeli SICURY outlet white
2P+E 16 A 250 V~ SICURY socket outlet, Israeli standard, white - 2 modules

Product Status
3 - Active

You may also be interested in

09240.R
09240.R - 2P+E 16A Israeli SICURY outlet red

Drawings

view encumbered art. 09240
PNG DXF
rear view art. 09240
PNG DXF
3D view art. 09240
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Model
Other
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
44,80 mm
Device height
47,00 mm
Device depth
39,20 mm

00. CE Marking - EU

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352408067
1 NR
5.1x4.3x5.3 [cm]
41 [g]
Barcode Qty 20 NR
8007352408074
20 NR
26.9x11.6x9 [cm]
898.8 [g]
Barcode Qty 240 NR
8007352420014
240 NR
38x28x35.5 [cm]
11,274 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
