2P+E 16A Israeli SICURY outlet red - 09240.R

Pdf
Vimar - 09240.R - 2P+E 16A Israeli SICURY outlet red
Vimar - 09240.R - 2P+E 16A Israeli SICURY outlet red

09240.R
Wiring devices / Traditional wiring devices / NEVE UP / Devices

2P+E 16A Israeli SICURY outlet red
2P+T 16 A 250 V~ SICURY socket outlet, Israeli standard, red - 2 modules

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Other
Number of modules (module system)
2
With hinged lid
No
Label space/information surface
Yes
Colour
Red
RAL-number (similar)
3001
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Anti-bacterial treatment
No
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Device width
44,80 mm
Device height
47,00 mm
Device depth
39,20 mm

00. CE Marking - EU

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352666108
1 NR
5.1x4.3x5.3 [cm]
41 [g]
Barcode Qty 20 NR
8007352666115
20 NR
26.9x11.6x9 [cm]
898.8 [g]
Barcode Qty 240 NR
8007352666122
240 NR
38x28x35.5 [cm]
11,274 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
