Actuator 1-10Vdc LED 120-230V MARINE - 01975

Pdf
Vimar - 01975 - Actuator 1-10Vdc LED 120-230V MARINE
Vimar - 01975 - Actuator 1-10Vdc LED 120-230V MARINE

01975
Smart systems&products / By-me Plus / Shared components / DIN devices

Actuator 1-10Vdc LED 120-230V MARINE
Actuator with 1-10 Vdc 30 mA output for LED control, 120-230 V~ 2,5 A change-over relay output, supply voltage 120-230 V~ 50/60 Hz, for DIN (60715 TH35) installation, occupies 3 17,5 mm modules. For MARINE sector

Product Status
3 - Active

Class group
Installation bus systems
Class
Dimming actuator for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequency)
No
Bus system radio frequency
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequency bidirectional
No
Model
Control module
Width in number of modular spacings
3
With bus connection
Yes
Bus module detachable
No
Local operation/hand operation
No
With LED indication
Yes
Number of outputs
2
Power boost suitable
No
Type of load
Universal and LED Retrofit
Voltage
120,00 - 230,00 V
Parallel-service possible
No
Frequency
50,00 - 60,00 HZ
Degree of protection (IP)
IP20

00. CE Marking - EU

37. Marking - Morocco

46. UK PSTI compliance

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352431553
1 NR
11.7x10.8x7.1 [cm]
177 [g]
