V72008
System infrastructure / Enclosures and control units / Junction boxes / Flush mounting
Junction box hollow walls 402x164x73,5mm
Flush mounting junction box for hollow walls with white cover and fixing screws.Dimensions 402x164x73.5 mm
产品状态
3 - Active
图纸
Class group
Connection material (electrotechnical)
Connection material (electrotechnical)
Class
Box/housing for built-in mounting in the wall/ceiling
Box/housing for built-in mounting in the wall/ceiling
Mounting method
Flush-mounted
Flush-mounted
Shape
Rectangular
Rectangular
Construction type
Cable junction box
Cable junction box
Model
Other
Other
Provided with revolving ring
No
No
Couplable
Yes
Yes
Equipped with
None
None
Diameter
0 mm
0 mm
Length
402,00 mm
402,00 mm
Width
402,00 mm
402,00 mm
Depth
0,00 - 73,50 mm
0,00 - 73,50 mm
Inner depth
73,50 mm
73,50 mm
For number of electric fittings
0
0
Mounting switching equipment
Spread
Spread
With screws
Yes
Yes
Housing feed-through by break-out opening
Yes
Yes
Housing feed-through by seal membrane
No
No
Housing feed-through by nozzle
No
No
Housing feed-through by step membrane
No
No
For tube diameter
Other
Other
Pipe locking
Yes
Yes
Pipe locking optional
Yes
Yes
Inlet from the rear
Yes
Yes
Number of inlets
22
22
Number of included spouts
0
0
Material
Plastic
Plastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Colour
Blue
Blue
Degree of protection (IP)
IP20
IP20
Cover model
Blind cover
Blind cover
Transparent cover
No
No
Cover attachment
Screwed
Screwed
Sealable
No
No
With screening
No
No
Air tight
No
No
Max. conductor cross section
0
0
Number of poles of the clamp
0
0
Clamp position fixed
No
No
Luminaire hook mounting
No
No
Nozzle
None
None
Special application
None
None
最小订单数量: 4 NR
条形码
8007352589971
1 NR
42.2x22.8x7.6 [cm]
638 [g]
8007352589988
4 NR
43x33x23 [cm]
3,055 [g]
