Horiz.dividing screen for flush-mountbox - V71551

Pdf
Vimar - V71551 - Horiz.dividing screen for flush-mountbox
Vimar - V71551 - Horiz.dividing screen for flush-mountbox

V71551
System infrastructure / Enclosures and control units / Connector block boxes / Installation accessories

Horiz.dividing screen for flush-mountbox
Horizontal dividing screen for V71320, V71321, V71620, V71720, 09920, 09921 mounting boxes, yellow. Allows to realize electrically separated compartments inside the box

产品状态
3 - Active

您可能也感兴趣

V71320
V71320 - Flush mounting box 12-14M light blue
V71321
V71321 - Flush mounting box 18-21M light blue

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Connection material (electrotechnical)
Class
Separation plate for junction box
Partition width
171,20 mm
Partition height
66 mm
Material
Plastic
Surface protection
Other

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

最小订单数量: 50 NR

条形码

Barcode Qty 1 NR
8007352119055
1 NR
17x6.5x0.2 [cm]
17.73 [g]
Barcode Qty 50 NR
8007352119062
50 NR
24.4x13.9x10.1 [cm]
973.73 [g]
