Flush mounting box 6-7M light blue - V71306

Pdf
Vimar - V71306 - Flush mounting box 6-7M light blue
Vimar - V71306 - Flush mounting box 6-7M light blue

V71306
System infrastructure / Enclosures and control units / Connector block boxes / Flush mounting

Flush mounting box 6-7M light blue
6-7-module flush mounting box (GW 650 °C), for masonry walls, light blue

  • Plenty of space of internal wiring
  • Knockouts designed for the insertion of pipes with various cross-sections
  • Rack for fixing the dividing screen (patented)
  • Fixing lug of the support screws with zinc-plating treatment to prevent the thread from clogging during installation and favour screwing
  • Accessories available: anti-mortar covers and coupling joints to create multiple series of boxes

产品状态
3 - Active

您可能也感兴趣

V71306.AU
V71306.AU - Flush mounting box 6-7M black
V71326
V71326 - Antimortar cover for flush-mount box 6M
V71550
V71550 - Dividing screen for flush-mount box yell
V71563
V71563 - Joint plate for flush-mount bixes yellow

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Connection material (electrotechnical)
Class
Box/housing for built-in mounting in the wall/ceiling
Mounting method
Flush-mounted
Shape
Rectangular
Construction type
Device connection box (round/square)
Model
Other
Provided with revolving ring
No
Couplable
Yes
Equipped with
None
Diameter
0 mm
Length
59,00 mm
Width
174,00 mm
Depth
0,00 - 49,60 mm
Inner depth
50,00 mm
For number of electric fittings
7
Mounting switching equipment
Screwing
With screws
No
Housing feed-through by break-out opening
Yes
Housing feed-through by seal membrane
No
Housing feed-through by nozzle
No
Housing feed-through by step membrane
No
For tube diameter
20/25 mm
Pipe locking
No
Pipe locking optional
No
Inlet from the rear
Yes
Number of inlets
9
Number of included spouts
0
Material
Plastic
Halogen free
Yes
Surface protection
Untreated
Colour
Blue
Degree of protection (IP)
IP00
Cover model
None
Transparent cover
No
Cover attachment
Screwed
Sealable
No
Circuit integrity
None
With screening
No
Air tight
No
Max. conductor cross section
0
Number of poles of the clamp
0
Clamp position fixed
No
Luminaire hook mounting
No
Nozzle
None
Special application
None

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

最小订单数量: 6 NR

条形码

Barcode Qty 1 NR
8007352079526
1 NR
18.4x9x5 [cm]
60 [g]
Barcode Qty 6 NR
8007352079533
6 NR
18.4x9x30 [cm]
367.27 [g]
Barcode Qty 48 NR
8007352079540
48 NR
62x26x30 [cm]
3,547.33 [g]
问题： What is the code for the cover that can be installed on this mounting box?
回答： Mounting box does not have any covers. The solution is to cover it with a mounting frame, cover plate or blank module.
