V70005
System infrastructure / Enclosures and control units / Junction boxes / Flush mounting
Flush junction box 154x128x70mm
Flush mounting junction box with white cover and fixing screws. Dimensions154x128x70 mm
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Connection material (electrotechnical)
Connection material (electrotechnical)
Class
Box/housing for built-in mounting in the wall/ceiling
Box/housing for built-in mounting in the wall/ceiling
Mounting method
Flush-mounted
Flush-mounted
Shape
Rectangular
Rectangular
Construction type
Device connection box (round/square)
Device connection box (round/square)
Model
Other
Other
Provided with revolving ring
No
No
Couplable
Yes
Yes
Equipped with
None
None
Diameter
0 mm
0 mm
Length
154,00 mm
154,00 mm
Width
179,00 mm
179,00 mm
Depth
0,00 - 70,00 mm
0,00 - 70,00 mm
Inner depth
70,00 mm
70,00 mm
For number of electric fittings
0
0
Mounting switching equipment
Spread
Spread
With screws
No
No
Housing feed-through by break-out opening
Yes
Yes
Housing feed-through by seal membrane
No
No
Housing feed-through by nozzle
No
No
Housing feed-through by step membrane
No
No
For tube diameter
Other
Other
Pipe locking
No
No
Pipe locking optional
No
No
Inlet from the rear
Yes
Yes
Number of inlets
16
16
Number of included spouts
0
0
Material
Plastic
Plastic
Halogen free
Yes
Yes
Surface protection
Untreated
Untreated
Colour
Blue
Blue
Degree of protection (IP)
IP00
IP00
Cover model
Blind cover
Blind cover
Transparent cover
No
No
Cover attachment
Screwed
Screwed
Sealable
No
No
Circuit integrity
None
None
With screening
No
No
Air tight
No
No
Max. conductor cross section
0
0
Number of poles of the clamp
0
0
Clamp position fixed
No
No
Luminaire hook mounting
No
No
Nozzle
None
None
Special application
None
None
最小订单数量: 44 NR
条形码
8007352082038
1 NR
17.9x15.3x7.5 [cm]
171.1 [g]
8007352453456
44 NR
59x39x44 [cm]
8,450 [g]
8007352453470
704 NR
120x80x190 [cm]
132,978.56 [g]
