V55308
System infrastructure / Enclosures and control units / Junction boxes / Surface mounting
IP56 junction box 240x190x90mm
Surface junction box with undrilled walls, transparent cover closed with stainless steel screws, RAL 7035 grey. Dimensions 240x190x90 mm
产品状态
2 - Will be discontinued
Class group
Connection material (electrotechnical)
Connection material (electrotechnical)
Class
Box/housing for surface mounting on the wall/ceiling
Box/housing for surface mounting on the wall/ceiling
Max. conductor cross section
0
0
Equipped with
None
None
Shape
Rectangular
Rectangular
Mounting method
Wall-/ceiling mounting
Wall-/ceiling mounting
Mounting in the soil
No
No
Mounting under water
No
No
For tube diameter
20/25 mm
20/25 mm
Inlet from the rear
No
No
Length
240,00 mm
240,00 mm
Width
265,00 mm
265,00 mm
Depth
96,00 mm
96,00 mm
Diameter
0 mm
0 mm
Tackable
No
No
Number of inlets
0
0
Type of housing feed-through
None
None
Material
Plastic
Plastic
Halogen free
No
No
Surface protection
Untreated
Untreated
Colour
Grey
Grey
Degree of protection (IP)
IP56
IP56
Cover model
Blind cover
Blind cover
Transparent cover
No
No
Cover attachment
Screwed
Screwed
Castable
No
No
With casting compound
No
No
Sealable
No
No
Rated insulation voltage Ui
450 V
450 V
Circuit integrity
None
None
With screening
No
No
Weatherproof
Yes
Yes
Operating temperature
0 - 60 °C
0 - 60 °C
Explosion-tested version
No
No
For Ex-zone gas
None
None
For Ex-Zone dust
None
None
00. CE Marking - EU
最小订单数量: 12 NR
条形码
8007352079762
1 NR
25x19.7x9.7 [cm]
589.4 [g]
8007352491724
12 NR
59x47x41 [cm]
7,917.6 [g]
