IP55 junction box 220x150x150mm

Pdf

Vimar - V55218 - IP55 junction box 220x150x150mm

V55218
System infrastructure / Enclosures and control units / Junction boxes / Surface mounting

IP55 junction box 220x150x150mm
Surface mounting junction box with undrilled walls, high blind cover closed with stianless steel screws, RAL 7035 grey. Dimensions 220x150x150 mm

产品状态
3 - Active

Class group
Connection material (electrotechnical)

Class
Box/housing for surface mounting on the wall/ceiling

Max. conductor cross section
0

Equipped with
None

Shape
Rectangular

Mounting method
Wall-/ceiling mounting

Mounting in the soil
No

Mounting under water
No

For tube diameter
20/25 mm

Inlet from the rear
No

Length
220,00 mm

Width
220,00 mm

Depth
60,00 mm

Diameter
0 mm

Tackable
No

Number of inlets
0

Type of housing feed-through
None

Material
Plastic

Halogen free
No

Surface protection
Untreated

Colour
Grey

Degree of protection (IP)
IP55

Cover model
Blind cover

Transparent cover
No

Cover attachment
Screwed

Castable
No

With casting compound
No

Sealable
No

Rated insulation voltage Ui
450 V

Circuit integrity
None

With screening
No

Weatherproof
Yes

Operating temperature
0 - 60 °C

Explosion-tested version
No

For Ex-zone gas
None

For Ex-Zone dust
None

00. CE Marking - EU

96. Electrotechnical expert

最小订单数量: 13 NR

条形码

8007352147799

1 NR

22x15x15 [cm]

487 [g]

8007352473430

13 NR

61x41.5x35 [cm]

7,900 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
