IP44 junction box 80x80x40mm

Pdf

Vimar - V55003 - IP44 junction box 80x80x40mm

V55003
System infrastructure / Enclosures and control units / Junction boxes / Surface mounting

IP44 junction box 80x80x40mm
Surface mounting junction box with cable entries, snap closed cover, RAL 7035 grey. Dimensions 80x80x40 mm

产品状态
3 - Active

Class group
Connection material (electrotechnical)

Class
Box/housing for surface mounting on the wall/ceiling

Max. conductor cross section
0

Equipped with
None

Shape
Square

Mounting method
Wall-/ceiling mounting

Mounting in the soil
No

Mounting under water
No

For tube diameter
20/25 mm

Inlet from the rear
No

Length
80,00 mm

Width
103,00 mm

Depth
44,00 mm

Diameter
0 mm

Tackable
No

Number of inlets
6

Type of housing feed-through
Trimmable step membrane

Material
Plastic

Halogen free
No

Surface protection
Untreated

Colour
Grey

Degree of protection (IP)
IP44

Cover model
Blind cover

Transparent cover
No

Cover attachment
Screwed

Castable
No

With casting compound
No

Sealable
No

Rated insulation voltage Ui
450 V

Circuit integrity
None

With screening
No

Weatherproof
Yes

Operating temperature
0 - 60 °C

Explosion-tested version
No

For Ex-zone gas
None

For Ex-Zone dust
None

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

最小订单数量: 6 NR

条形码

8007352077003

1 NR

10.4x10.4x4.4 [cm]

71 [g]

8007352077010

6 NR

10.4x10.4x26.5 [cm]

428 [g]

8007352115712

54 NR

38.5x29x30 [cm]

4,400 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
