Three push buttons - R14540

Pdf
Vimar - R14540 - Three push buttons
Vimar - R14540 - Three push buttons

R14540
Smart systems&products / By-me Plus / PLANA / Devices

Three push buttons
Spare control device with three simple push buttons, to be completed with 1 or 2 module interchangeable buttons - 3 modules

产品状态
3 - Active

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
3
Number of modules (module system)
300
Number of poles
0
Nominal voltage
29 V
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Transparent
No
Label space/information surface
Yes
Imprint
None
Suitable for degree of protection (IP)
IP40
Device width
67,30 mm
Device height
49,00 mm
Device depth
46,60 mm

00. CE Marking - EU

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352616882
1 NR
11.2x9.6x9.8 [cm]
136.4 [g]
