7509/D04
ELVOX Door entry system / 2F/2F+ video door entry system / Audio / Audio indoor stations
Tab h-o-h interphone w/handset, black
Surface mounting Tab interphone for Due Fili system with handset, loudspeaker for electronic calls, capacitive keypad for interphone functions and intercom calls, facility for hard of hearing function, screws for fixing in round or rectangular mounting box, black
产品状态
2 - Will be discontinued
Class group
Communication technique
Communication technique
Class
Intercom
Intercom
Installation technique
Bus system
Bus system
Mounting method
Wall-/desk type model
Wall-/desk type model
最小订单数量: 1 NR
条形码
8013406227003
1 NR
22.5x21.7x8.4 [cm]
646 [g]
8013406229663
8 NR
60x37.5x27 [cm]
5,168 [g]
8013406305268
10 NR
28x24.5x21 [cm]
6,460 [g]
| 问题： | How do you encode door entry units art. 7509 - Tab series - setting the primary and secondary identifier? |
|---|---|
| 回答： | Encoding the main ID code: 1_ Lift the handset and press the Bell and Self-start buttons, holding them down until the Bell button starts to flash. 2_ Release the buttons. 3_ Within 5 seconds from release, press the Lock button and hold down until a warning beep is given from the indoor station, and communication between this and the external electronic unit has been established. 4_ Release the Lock button. 5_ Press the button (which?) or type in the code you wish to assign into the entrance panel. Encoding the secondary ID code: Lift the handset and press the Bell and Self-start buttons, holding them down until the Bell button starts to flash. 2_ Release the buttons. 3_ Within 5 seconds from release, press the Lock and Self-start buttons and hold down until a warning beep is given from the indoor station, and communication between this and the external electronic unit has been established. 4_ Release the Lock and Self-start buttons. 5_ Press the button (which?) or type in the code you wish to assign into the entrance panel. |
