Video transducer Balun+power supp.2ch.2p - 46862.B01

Pdf
Vimar - 46862.B01 - Video transducer Balun+power supp.2ch.2p
Vimar - 46862.B01 - Video transducer Balun+power supp.2ch.2p

46862.B01
Safety / ELVOX CCTV / AHD / Accessories

Video transducer Balun+power supp.2ch.2p
Pair of Balun video passive transducers (transmitter/receiver) for video transmission on twisted pair, BNC connector for the video, jack for the power supply, cable connection with RJ45 connector, maximum distance attainable with CAT5 cable 50 m, compatible with PAL/NSC/SECAM, built-in electrostatic discharge protection

产品状态
3 - Active

Class group
Data and telecommunication
Class
Balun
Application
Other
Connection 1
BNC
Connection type connection 1
Plug
Impedance connection 1
75 Ohm
Pin assignment connection 1
Other
Connection 2
Other
Connection type connection 2
Plug
Impedance connection 2
100 Ohm
Pin assignment connection 2
Other
Screened
Yes
Compatible with Grade2TV according to XP-C 90-483
No
Compatible with Grade3TV according to XP-C 90-483
No

00. CE Marking - EU

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8013406261038
1 NR
8.4x8x3.8 [cm]
72.5 [g]
