16-port Ethernet switch PoE at 2Eth 1SFP - 46260.16P.02

Pdf
Vimar - 46260.16P.02 - 16-port Ethernet switch PoE at 2Eth 1SFP
Vimar - 46260.16P.02 - 16-port Ethernet switch PoE at 2Eth 1SFP

46260.16P.02
Safety / ELVOX CCTV / IP / Networking

16-port Ethernet switch PoE at 2Eth 1SFP
Fast Ethernet switch with 16 PoE Standard IEEE 802.3af/at (End-Span 1/2+ ,3/6-) ports 10/100 Mbps auto-sensing, auto MDI/MDI-X, working LED + 2 Uplink 10/100/1000 Mbps + 1SFP Combo ports. Supported with 10/100 BASE-TX, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3Z standards, MAC 4K table. Power supply 100-240 Vac.Dimensions: 442×285×44.5 mm

产品状态
3 - Active

单, 说明书, 文档

Class group
Data and telecommunication
Class
Network switch
Ethernet
Yes
Number of ports 10/100 Mbps RJ45
16
Number of ports 10/100/1000 Mbps RJ45
2
Number of ports 1000 Mbps RJ45
2
Number of ports 10 Gbps RJ45
0
Number of ports 10 Gbps Mini GBIC
0
Number of ports 100/1000 Mbps Mini GBIC
0
Number of ports 1000 Mbps Mini GBIC
0
Number of ports 40 Gbps Mini GBIC
0
Number of ports 100 Gbps Mini GBIC
0
Number of combination-ports RJ45/Mini GBIC
0
Number of ports 1000 Mbps GBIC
0
Number of ports 10/100 Mbps M12
0
Number of ports 100 Mbps SC
0
Number of ports 1000 Mbps SC (SX)
0
Number of ports 1000 Mbps SC (LX)
0
Number of ports 100 Mbps ST
0
Number of ports 100 Mbps POF
0
Number of ports 1000 Mbps POF
0
Number of other ports
18
Power over Ethernet (PoE)
802.3 at (PoE+)
Number of ports PoE
16
Max. PoE power
180 W
Redundant power supply
No
Mounting method
Empty chassis
Manageable
No
Degree of protection (IP)
Other
Height
44,50 mm
Width
442,0 mm
Depth
285,00 mm
Compatible with Grade2TV according to XP-C 90-483
No
Compatible with Grade3TV according to XP-C 90-483
No

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8013406307187
1 NR
58.5x37x11 [cm]
5,180 [g]
Barcode Qty 3 NR
8013406307361
3 NR
62x37x41 [cm]
16,190 [g]
