4622.2812GAE
Safety / ELVOX CCTV / IP / Cameras
IP Dome Plus motorcam-6Mpx 2,8-12mm IK10
产品状态
3 - Active
Class group
Alarm installations, emergency call and signalling
Alarm installations, emergency call and signalling
Class
Camera for surveillance system
Camera for surveillance system
Model
Standard (Fixed)
Standard (Fixed)
Mounting method
Wall/ceiling
Wall/ceiling
Scope of application
Universal
Universal
Transmission
Other
Other
Protocol
TCP/IP
TCP/IP
Power over Ethernet (PoE)
802.3 af (PoE)
802.3 af (PoE)
Picture system
PAL
PAL
Property picture system
Colour
Colour
Focal size
2,80 - 12,00 mm
2,80 - 12,00 mm
Colour
White
White
Wireless
No
No
Type of interface
Other
Other
Number of pixels (Megapixel)
6
6
Memory capacity
256
256
With lens
Yes
Yes
With IR lamp
Yes
Yes
Max. infrared reach
50 m
50 m
Number of digital inputs
1
1
Number of digital outputs
1
1
Number of audio inputs
1
1
Number of audio outputs
1
1
Vandal proof
Yes
Yes
Impact strength
IK10
IK10
With video motion detector
Yes
Yes
Degree of protection (IP)
IP67
IP67
Horizontal field of view
37,00 - 109,00
37,00 - 109,00
Power consumption
8,40 W
8,40 W
Supply voltage
12,00 - 12,01 V
12,00 - 12,01 V
Voltage type
DC
DC
Diameter
14.100,00 mm
14.100,00 mm
Height
100,00 mm
100,00 mm
Width
141,00 mm
141,00 mm
Depth
100,00 mm
100,00 mm
Compatible with Apple HomeKit
No
No
Compatible with Google Assistant
No
No
Compatible with Amazon Alexa
No
No
IFTTT support available
No
No
ONVIF-compliant
Yes
Yes
最小订单数量: 1 NR
条形码
8007352753778
1 NR
18x18x17.8 [cm]
1,174.2 [g]
分享
合法
Vimar保留随时修改所示产品的特性的权利，恕不另行通知。 安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。 有关产品卡信息的使用条件，请参阅 使用条件。
