Power unit DIN 100-240V~ 50/60Hz 32Vdc - 40105

Pdf
Vimar - 40105 - Power unit DIN 100-240V~ 50/60Hz 32Vdc
Vimar - 40105 - Power unit DIN 100-240V~ 50/60Hz 32Vdc

40105
ELVOX Door entry system / Other video door entry systems / Shared A/V components / System components

Power unit DIN 100-240V~ 50/60Hz 32Vdc
Power supply unit for IPo2W video door entry system with 32 Vdc 3.5 A output, 100-240 V~ 50/60 Hz power supply, installation on DIN rail (60715 TH35), occupies 8 modules size 17.5 mm

产品状态
3 - Active

Class group
Communication technique
Class
Power supply door communication
Application
Other
Input voltage
240 V
Frequency
50,00 - 60,00 HZ
Type of current
DC
Output voltage
32,00 V
Max. output current
4.000,0 mA
Short-circuit-proof
Yes
Degree of protection (IP)
IP20
Width in number of modular spacings
8
Installation technique
2-wire
Integrated door opening circuit
No
Control function
No
Evaluation function
No
Service indication
Yes
Mounting method
DIN rail
Programming lock
No
With contact
No

00. CE Marking - EU

37. Marking - Morocco

92. RoHS UAE

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352708716
1 NR
21.4x10.8x7 [cm]
561 [g]
