IoT roller shutter control mechanism - 30804

Pdf

Vimar - 30804 - IoT roller shutter control mechanism

30804
Wiring devices / View Wireless wiring devices / LINEA / Devices

IoT roller shutter control mechanism
VIEW Wireless electronic control mechanism for 1 roller shutter with slat orientation and change-over relay output for cosφ 0.6 motor 2 A 100-240 V~, local or remote control, double IoT technology on Bluetooth 5.0 standard for the creation of VIEW Wireless mesh system and on Zigbee 3.0 standard, 1 input for external push button to recall a scenario, favourite position recall function, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, to be completed with Linea 1-module interchangeable buttons

Compatible with SmartThings hub

产品状态
3 - Active

您可能也感兴趣

31000A.FG - Axial button 1M arrow symbol black

31000A.FB - Axial button 1M arrow symbol white

31000A.FC - Axial button 1M arrow symbol canvas

30807.G - IoT connected Gateway 2M black

30807.B - IoT connected Gateway 2M white

30807.C - IoT connected Gateway 2M canvas

单, 说明书, 文档

视频

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Push button

Number of contacts as normally closed contact
0

Number of contacts as normally open contact
2

Number of contacts as change-over contact
0

Number of revolving contacts
0

Contactless type
No

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Nominal voltage
240 V

Rated current
2,00 A

With lighting
Yes

With light source
Yes

With signal lamp
No

Feedback-signal contact
No

Connection type
Screwed terminal

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Anti-bacterial treatment
No

Surface protection
Untreated

Surface finishing
Matt

Colour
Black

RAL-number (similar)
7024

Transparent
No

Label space/information surface
No

Imprint
None

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
52,80 mm

Device depth
44,70 mm

Compatible with Apple HomeKit
Yes

Compatible with Google Assistant
Yes

Compatible with Amazon Alexa
Yes

IFTTT support available
No

00. CE Marking - EU

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352688971

1 NR

5.1x3.5x5.5 [cm]

44 [g]

8007352744868

60 NR

27x23x12.5 [cm]

3,113.28 [g]
