Vimar - 30617 - Frame 7M + screws
Vimar - 30617 - Frame 7M + screws

30617
Wiring devices / Traditional wiring devices / LINEA / Mounting frames

Frame 7M + screws
7-module mounting frame, with screws, for 6/7-module mounting boxes

产品状态
3 - Active

您可能也感兴趣

30617.C
30617.C - Linea 7M mounting frame protection
30613
30613 - Frame 3M + screws
30614
30614 - Frame 4M + screws
30040.B
30040.B - 1/2M blank module white
30040.C
30040.C - 1/2M blank module canvas
30040.G
30040.G - 1/2M blank module black

图纸

PNG DXF
PNG DXF
PNG DXF
Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with screw
With nail
No
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
7
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
Yes
Suitable for mounting in round junction box 60 mm
No
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated

00. CE Marking - EU

01. IMQ - Italy

96. Electrotechnical expert

最小订单数量: 30 NR

条形码

Barcode Qty 1 NR
8007352703445
1 NR
20x7.9x2.6 [cm]
50.5 [g]
Barcode Qty 30 NR
8007352703452
30 NR
28.4x24.4x14.9 [cm]
1,692 [g]
Barcode Qty 120 NR
8007352703469
120 NR
62x26x30 [cm]
7,364 [g]
