30602
Wiring devices / Traditional wiring devices / LINEA / Mounting frames
Frame 2M + claws 71mm
2-module mounting frame, with claws, for flush mounting box ø 60 mm, modular with distance between centres of 71 mm. Remove the thickness shim when used with plasterboard walls.
产品状态
3 - Active
您可能也感兴趣
图纸
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Mounting method
Mounting with claw and screw
Mounting with claw and screw
With nail
No
No
Mounting method of the module inserts
Front side
Front side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
2
2
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
No
No
Suitable for mounting in round junction box 60 mm
Yes
Yes
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Surface protection
Untreated
Untreated
最小订单数量: 50 NR
条形码
8007352681422
1 NR
7.4x7.4x2.5 [cm]
32.6 [g]
8007352681439
50 NR
28.4x24.4x11.9 [cm]
1,763 [g]
8007352681446
300 NR
59.5x38.5x26.5 [cm]
11,328 [g]
