4-button control+dimmer 0/1-10V 2M - 30489

Pdf

Vimar - 30489 - 4-button control+dimmer 0/1-10V 2M

30489
Smart systems&products / By-me Plus / LINEA / Devices

4-button control+dimmer 0/1-10V 2M
By-me Plus home automation control device with four push buttons, 1 0/1-10 V SELV output, 1 NO contact relay output 2 A 120-240 V~ 50/60 Hz for ballast and LED driver, RGB LED visible in darkness with brightness control, to be completed with 1- or 2-module interchangeable half-button caps - 2 modules

产品状态
3 - Active

您可能也感兴趣

31480.RG - 2 half buttons 1M control black

31480.RB - 2 half buttons 1M control white

31480.RC - 2 half buttons 1M control canvas

31480.2RG - 2 half buttons 2M control black

31480.2RB - 2 half buttons 2M control white

31480.2RC - 2 half buttons 2M control canvas

单, 说明书, 文档

图纸

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Multi operating device for bus system

Bus system KNX
No

Bus system KNX-RF (Radio Frequent)
No

Bus system radio frequent
No

Bus system LON
No

Bus system Powernet
No

Other bus systems
Other

Radio frequent bidirectional
No

Mounting method
Flush-mounted

Width in number of modular spacings
2

Number of actuation points
4

With display
No

Status-LED
Yes

IR sensor
No

Manual set point setting
No

Presence button
No

With temperature controller
No

With integrated DCF77 receiver
No

With time switch clock
No

With anti-theft/dismantling protection
No

Central functional unit for senders/actuators
Yes

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Matt

Colour
Other

RAL-number (similar)
7024

Transparent
No

Degree of protection (IP)
IP40

With bus connection
Yes

00. CE Marking - EU

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

8007352685840

1 NR

6x5.4x5.2 [cm]

71.8 [g]

8007352685857

10 NR

28.1x13.1x6 [cm]

806.3 [g]
