4-button Home autom.control+actuator 2M - 30481

Pdf
Vimar - 30481 - 4-button Home autom.control+actuator 2M
Vimar - 30481 - 4-button Home autom.control+actuator 2M

30481
Smart systems&products / By-me Plus / LINEA / Devices

4-button Home autom.control+actuator 2M
Home automation control device with four push buttons and actuator with NO relay output 16 A 120-240 V~ 50/60 Hz, RGB LED visible in darkness with brightness control, to be completed with two 1- or 2-module interchangeable half-button caps - 2 modules

产品状态
3 - Active

您可能也感兴趣

31480.G
31480.G - 2 half buttons 1M w/o symbol cust.black
31480.B
31480.B - 2 half buttons 1M w/o symbol cust.white
31480.C
31480.C - 2 half butt. 1M w/o symbol cust. canvas
31480.2G
31480.2G - 2 half buttons 2M w/o symbol cust.black
31480.2B
31480.2B - 2 half buttons 2M w/o symbol cust.white
31480.2C
31480.2C - 2 half buttons 2M w/o symbol cust.canvas
Class group
Installation bus systems
Class
Multi operating device for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Mounting method
Flush-mounted
Width in number of modular spacings
2
Number of actuation points
4
With display
No
Status-LED
Yes
IR sensor
No
Manual set point setting
No
Presence button
No
With temperature controller
No
With integrated DCF77 receiver
No
With time switch clock
No
With anti-theft/dismantling protection
No
Central functional unit for senders/actuators
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Other
RAL-number (similar)
7024
Transparent
No
Degree of protection (IP)
IP40
With bus connection
Yes

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352677449
1 NR
6x5.4x5.2 [cm]
62.6 [g]
Barcode Qty 60 NR
8007352677463
60 NR
37.5x30x13.5 [cm]
4,094 [g]
