Dial thermostat 100-240V 2M white - 30440.B

Pdf
Vimar - 30440.B - Dial thermostat 100-240V 2M white
Vimar - 30440.B - Dial thermostat 100-240V 2M white

30440.B
Wiring devices / Traditional wiring devices / LINEA / Devices

Dial thermostat 100-240V 2M white
Dial thermostat with relay output 5(2) A 240 V~, heating and air conditioning in ON/OFF MODE, class I temperature control device (contribution 1%), white LED backlighting with brightness control, 100-240 V 50/60 Hz power supply, to be completed with cover plate, white - 2 modules

  • Simple programming
  • Suitable for all heating or cooling systems
  • Maximum simplicity thanks to the large knob
  • Hotkeys are designed for quick interaction

产品状态
3 - Active

Class group
Stats, switches and controllers
Class
Room thermostat
Model
On/Off
Type of power supply
230 V AC
Connection
2-wire
With receiver
No
Measuring range
0 - 40 °C
External sensor
No
Thermal feedback
Parallel
Control characteristic
Other
Suitable for heating
Yes
Number of heater outputs
1
Suitable for cooling
Yes
Number of cooler outputs
1
Differential value
0,30 - 0,31 k
Adjustable differential
No
Temperature readable
Yes
With sound indicator
No
Sensor/feeler type
Resistance sensor
Mounting method
Flush-mounted
Number of modules (module system)
2
With display
Yes
Operation
Turn
With tap water circuit
No
Contact type
Normally open contact (NO)
Max. contact voltage
230 V
Max. contact load
5 A
Degree of protection (IP)
IP20
Degree of protection (NEMA)
Other
Explosion-proof
No
Colour
White
RAL-number
9016
Height
52,80 mm
Width
44,80 mm
Depth
41,70 mm
Diameter
0 mm
Class of the temperature control
I
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 1 NR

条形码

Barcode Qty 1 NR
8007352695917
1 NR
6x5.4x5.2 [cm]
69.2 [g]
Barcode Qty 10 NR
8007352695924
10 NR
28.1x13.1x6 [cm]
780.2 [g]
Barcode Qty 120 NR
8007352695931
120 NR
40x30x27 [cm]
9,839 [g]
