Vimar - 30386.C - Neutral indicator unit canvas

30386.C
Wiring devices / Traditional wiring devices / LINEA / Devices

Neutral indicator unit canvas
Signalling unit pilot light, neutral diffuser, canvas. Supplied without signalling unit

产品状态
3 - Active

您可能也感兴趣

00936.250.R - LED unit 250V 0,35W red

00936.250.G - LED unit 250V 0,35W green

00936.250.W - LED unit 250V 0,35W white

00935.G - LED unit 12-24V 0,1W green

00935.W - LED unit 12-24V 0,1W white

图纸

PNG DXF

Class group
Domestic switching devices

Class
Information light signal for domestic switching devices

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Lamp holder
Other

With light source
No

Lamp type
LED exchangeable

With flashlight
No

With fixed symbol/imprint
No

With exchangeable symbol
No

Application as button
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Beige

RAL-number (similar)
7032

Transparent
No

Colour light source
White

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Max. lamp power
1 W

Device width
22,2 mm

Device height
52,8 mm

Device depth
26,8 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352700239

1 NR

3.6x2.7x5.6 [cm]

19.16 [g]

8007352700246

10 NR

14.2x7.8x6.2 [cm]

191.6 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
