Vimar - 30318.B - F type female socket connector white

30318.B
Wiring devices / Traditional wiring devices / LINEA / Devices

F type female socket connector white
Coaxial socket outlet with female connector type F (IEC 60169-24), white. For frequencies up to 2400 MHz. Connection at input and output via male connector type F 01654

产品状态
3 - Active

图纸

PNG DXF

Class group
Antenna and satellite technique

Class
Antenna socket box

Model
End socket

Mounting method
Flush-mounted

Number of modules (module system)
1

Cover
None

Number of outlets
1

Suitable for cable modem
No

Suitable for remote power supply
Yes

Type of fastening
Snap mounting (engagement)

Colour
White

RAL-number (similar)
9016

Surface protection
Untreated

Surface finishing
Matt

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Anti-bacterial treatment
No

Degree of protection (IP)
IP20

Device width
2.230,00 mm

Device height
5.280,00 mm

Device depth
2.985,00 mm

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352681187

1 NR

3.6x2.7x5.6 [cm]

14.4 [g]

8007352681194

10 NR

14.2x7.8x6.2 [cm]

183.2 [g]

8007352681200

160 NR

34x30x15 [cm]

3,272 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
