1P 10AX 2-way switch for fan-coil white

Pdf

Vimar - 30063.B - 1P 10AX 2-way switch for fan-coil white

30063.B
Wiring devices / Traditional wiring devices / LINEA / Devices

1P 10AX 2-way switch for fan-coil white
1P 10 AX 250 V~ switch for fan coil, with two buttons and central OFF position, white. Max 100 W for lamps with built-in power supply unit (IEC 60669-1:2017)

产品状态
3 - Active

图纸

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Other

Number of contacts as normally closed contact
0

Number of contacts as normally open contact
0

Number of contacts as change-over contact
0

Number of revolving contacts
0

Contactless type
No

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
No

With light source
No

With signal lamp
No

Feedback-signal contact
No

Connection type
Screwed terminal

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Anti-bacterial treatment
No

Surface protection
Untreated

Surface finishing
Matt

Colour
White

RAL-number (similar)
9016

Transparent
No

Label space/information surface
No

Imprint
Other

Suitable for degree of protection (IP)
IP40

Impact strength
Other

Device width
22,20 mm

Device height
52,60 mm

Device depth
31,40 mm

Compatible with Apple HomeKit
No

Compatible with Google Assistant
No

Compatible with Amazon Alexa
No

IFTTT support available
No

00. CE Marking - EU

13. SNI-MGI - Indonesia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

最小订单数量: 10 NR

条形码

8007352715035

1 NR

4.6x2.7x5.6 [cm]

28.5 [g]

8007352715042

10 NR

14.6x10x6.6 [cm]

370 [g]

合法

Vimar保留随时修改所示产品的特性的权利，恕不另行通知。安装必须由符合资质的人员执行，严格遵守所在国家现行的电气材料安装相关规定。有关产品卡信息的使用条件，请参阅使用条件。
